EMB-H61A

编号: EMB-H61A
销量: 0
产品详情



      EMB-H61A是搭载第二代/第三代英特尔®酷睿™ i5处理器和英特尔®H61芯片组的Mini-ITX板型主板。它的两个SODIMM可以支持最多16GB的DDR3 1066/1333内存。而2个SATA 3.0Gb/s接口则提供了充足的存储空间。板上还提供了8个USB2.0端口、1个键盘/鼠标接口和8个COM端口。用户可以通过1个PCI-Express(x4)、1个Mini-Card(mSATA可选)和TPM进行功能扩展。EMB-H61A带有2个有助于实现快速互联网连接的千兆以太网端口。它还支持通过VGA、DVI、LVDS和HDMI实现的独立双显。

应用

  • 博彩机

  • 工业控制自动化

  • 通讯

  • 交通运输

  • 医疗设备

  • Intel® Socket 1155 for 2nd/3rd Generation Core™ I7/i5/i3 Processor Up to 65W

  • Intel® H61

  • Dual-Channel DDR3 1333/1066 MHz SODIMM x 2, Up to 16 GB

  • Gigabit Ethernet x 2

  • Intel® Integrated Graphics Engine Supports Dual Display By VGA, DVI, HDMI, LVDS

  • HD 5.1CH Audio

  • SATA 3.0Gb/s x 2

  • USB2.0 x 8 , COM x 6

  • PCI-Express〔x4〕x 1, Mini-Card x 1 (mSATA optional), TPM

技术规格:

SYSTEM
PROCESSORLGA1155 socket for Intel® 3rd/2nd Generation Core™ i7/ i5/ i3/ Pentium® / Celeron® Processors (Supports Intel® 32 nm CPU up to 35W)
CHIPSETIntel® H61
MEMORYDDR3 1333/1600 MHz SODIMM x 2, Up to 16GB, Non-ECC, Dual-channel memory architecture
GRAPHICSIntel® HD Graphics
I/O CHIPSETFintek F81866D-I
ETHERNETRealtek PCIe Gb LAN 8111E x 2
AUDIORealtek® ALC887
TPMInfineon SLB9635 TT 1.2
EXPANSION SLOTPCIe [x4] x 1, Full-size Mini-Card (PCIe + USB) (mSATA optional)+ SIM Card x 1
BIOS64 M bit Flash ROM, AMI BIOS
H/W MONITORTemperature Monitor on CPU/System, Voltage Monitor on Vcore/5V/3.3V/12V, Fan Monitor on CPU/Chassis
WATCHDOG TIMER1~255 step by software program
SMART FAN CONTROLCPU Fan/ Chassis Fan
WAKE ON LAN/ PXEYes (WOL/PXE)
POWER STATES1, S3, S4, S5
GRAPHICS
GRAPHICS CHIPSETIntel® HD Graphics
GRAPHICS MULTI DISPLAYVGA+LVDS, VGA+HDMI, VGA+DVI, LVDS+HDMI, LVDS+DVI, HDMI+DVI
VGAUp to 2048 x 1536 @ 75 Hz
DVIUp to 1920 x 1200 @60 Hz
HDMIUp to 1920 x 1200 @60 Hz
DISPLAYPORT
LVDSUp to 1920 x 1200 @60 Hz, Dual Channel 18/24-bit
EDP
BACKLIGHT CONTROLVoltage / PWM
ENVIRONMENTAL & POWER & ME
BATTERYLithium battery
POWER REQUIREMENT12V DC with 4pin Power connector x 1
OPERATING TEMPERATURE32~131°F (0~55°C)
STORAGE TEMPERATURE-40°F ~185°F (-40°C ~85°C)
OPERATING HUMIDITY0% ~ 90%RH, non-condensing
CERTIFICATIONCE & FCC
FORM FACTORMini-ITX, 6.7” x 6.7” (170mm x 170mm)
WEIGHT1.1 lb (0.5 Kg)
MTBF (HOURS)117673
REAR I/O PORTS
USBUSB 2.0 x 6
DISPLAY I/OVGA x 1, DVI-D x 1, HDMI x 1
AUDIO I/OMic-in x 1, Line in x 1, Line-out x 1
LAN I/OLAN (RJ-45) port x 2
SERIAL PORTCOM (RS-232/422/485) x 1
PS/2 PORTPS/2 Keyboard Mouse Connector x 1
OTHERS
INTERNAL I/O CONNECTORS
STORAGESATA connectors x 2, SATA power connector x 1, Mini-Card slot x 1
USBUSB 2.0 connectors support additional 2 USB port x 1
DISPLAY I/OLVDS connector x 1, LVDS Power select jumper x 1, LVDS Brightness Control Type Selection x 1, LVDS Panel Backlight Power Selection x 1, LCD_POWER 5 pin connector x 1
AUDIO I/O
SERIAL PORTCOM header x 5 (RS-232)
PS/2 PORT
PARALLEL PORT
DIODigital I/O header x 1
FANCPU Fan connector x 1, Chassis Fan connector x 1
POWER12V AUX Power Connector x 1, AT/ATX mode select jumper x 1
OTHERSSIM Card Socket x 1, Front Panel connector x 1, CMOS jumper x 1
OS
OS SUPPORTWindows® XP 32-bit, Windows® 7 32/64-bit, Linux Fedora
